5V noise/sound sensor with potentiometer for Arduino AVR, 2.54 mm

5V noise and sound sensor with potentiometer

The sound and noise sensor module is a versatile solution compatible with popular microcontroller platforms. It works excellently as an add-on for Arduino, for ESP8266, for ESP32, and for Raspberry Pi. The device features a built-in condenser microphone and a precise potentiometer for sensitivity adjustment.

The sensor allows registering a defined noise level from the environment or detecting loud, sudden sounds such as a clap. The sensor is powered by 5V and has a digital output, which greatly simplifies its use. The module’s compact dimensions of just 32 mm x 15 mm allow trouble-free integration in a wide range of electronic projects.

Key technical features

• Supply voltage: 5V
• Output: digital with adjustable sensitivity
• Sensor: built-in condenser microphone
• Adjustment: integrated potentiometer on the board
• Dimensions: 32 mm x 15 mm

Example applications

• Smart lighting projects controlled by sound
• Home alarm systems that react to noise
• Room loudness monitors
• Interactive installations and electronic devices
• Building automation systems that detect presence based on sound

Benefits

• Simple integration with the most popular microcontrollers on the market
• Easy calibration thanks to the built-in potentiometer for smooth sensitivity adjustment
• Compact size suitable for mounting in space-constrained projects
• Reliable operation based on a proven condenser microphone
• Quick setup thanks to a simple digital interface and 5V power supply
