8-channel Saleae 24 MHz logic analyzer I2C SPI 1-Wire CAN I2S

Product description - Saleae 24 MHz 8-channel logic analyzer

Saleae 24 MHz 8-channel logic analyzer is an indispensable tool when working with microcontrollers such as ARM, STM32, AVR, PIC, and Arduino, and it also offers excellent support for ESP8266, ESP32, and Raspberry Pi. The kit includes the analyzer, a USB cable, and the necessary leads. The device is fully compatible with original SALEAE hardware and works seamlessly with the dedicated software, offering professional support for a wide range of electronic projects.

The analyzer enables precise reading and recording of logic states directly on your computer. It supports hardware decoding of many popular communication protocols, including:

• I2C
• SPI
• 1-Wire
• CAN
• I2S
• PCM
• Manchester
• and many others

Key technical specifications

• Number of channels: 8 independent logic inputs
• Input impedance: 100K Ohm
• Maximum sampling rate: 24 MHz
• Available sampling rates: 24 MHz, 16 MHz, 12 MHz, 8 MHz, 4 MHz, 2 MHz, 1 MHz, 500 KHz, 250 KHz, 100 KHz, 50 KHz, 25 KHz
• Maximum sampling length: 1G (at 1 MHz sampling you can capture 1024 s of signal, at 2 MHz - 512 s, etc.)
• Power: directly from USB port
• Indication: built-in LED indicator and input indicator (0-1 LED)
• Design: compact size for easy use and transport

Example applications

• Diagnosing and debugging communication errors between the microcontroller and digital sensors
• Analysing data transfer on I2C, SPI, and 1-Wire buses in embedded systems
• Monitoring and decoding frames on automotive or industrial CAN bus
• Verifying correct digital audio transfer via I2S or PCM interface
• Reverse engineering and investigating unknown communication protocols in IoT projects

Benefits

• Fast and reliable identification of communication issues in digital circuits under development
• Significant time savings thanks to automated decoding of the most popular protocols
• Convenient operation powered from USB - no need for additional power supplies
• Long-term recording and analysis of signals thanks to huge sampling memory up to 1G
• Full versatility thanks to compatibility with many microcontroller families and single-board computers
