Ai-WB2-32S-Kit WiFi Bluetooth 5.0 IBL602 module RISC AI-Thinker architecture
Availability:
duża ilość
Dispatched within:
1 day
Rating:
0
0
Vendor:
OEM
Description
The Ai-WB2-32S-Kit is equipped with a board-integrated antenna and operates in the frequency range from 2400 to 2483.5MHz. It provides stable operation at temperatures from -40°C to 85°C with a supply voltage of 3.3V or 5V and a current consumption of 500mA. The module offers a variety of communication ports such as UART, GPIO, ADC, PWM, I2C, SPI and has 15 I/O ports. The default baud rate of the serial port is 115200 bps, which enables fast and efficient data exchange. WiFi connection security is guaranteed by WPS, WEP, WPA, WPA2 Personal, WPA2 Enterprise and WPA3 protocols. The module has 4MB of Flash memory and is housed in a 55.05 x 25.4(±0.2) mm DIP-38 enclosure.
Specification:
- Model: Ai-WB2-32S-Kit
- Antenna: embedded on board
- Operating frequency: 2400 ~ 2483.5MHz
- Operating temperature: -40°C ~ 85°C
- Supply voltage: 3.3V or 5V
- Current consumption: 500mA
- Communication ports: UART/GPIO/ADC/PWM/I2C/SPI
- Number of I/O ports: 15
- Default serial port baud rate: 115200 bps
- WiFi security: WPS/WEP/WPA/WPA2 Personal/WPA2 Enterprise/WPA3
- Flash memory: 4MB
- Housing: DIP-38
- Dimensions: 55.05*25.4(±0.2)mm
