Fan 80x80x25mm 12V 2 PIN XH cable 25 cm double bearings

Fan 80x80x25mm 12V DC 2PIN

A reliable and efficient solution for cooling electronic devices. Thanks to its robust construction and double metal bearings, it provides long-lasting and quiet operation. It is an excellent choice for professionals and computer hardware enthusiasts.

Key technical specifications

• Model: 8025
• Supply voltage: 12V DC
• Dimensions: 80 mm x 80 mm x 25 mm
• Rotational speed: 3644 ± 5% RPM
• Bearing type: Oil / double metal bearings
• Operating temperature range: -10°C to +60°C
• Rated current: 0.25A
• Power consumption: 3.0W
• Noise level: 28.3 DBA
• Connector: 2-pin XH 2.54 mm on a 25 cm cable
• Mounting hole spacing: 70 mm x 70 mm (diagonal 100 mm)
• Wiring: Red wire - positive, black wire - negative
• Storage humidity: 5% to 95% RH

Benefits

• Effective cooling thanks to high rotational speed 3644 RPM.
• Long service life and reliability ensured by double metal bearings.
• Nearly silent operation with a noise level of just 28.3 DBA.
• Easy installation in many cases thanks to universal dimensions and standard hole spacing.
• Quick connection with a factory-terminated XH 2.54 mm connector.

Example applications

• Cooling electronic devices and power supplies.
• Ventilation in PC and server enclosures.
• Heat dissipation in DIY projects and embedded systems.
• Cooling components in control cabinets.
• Replacing worn fans in workshop and industrial equipment.

The 80x80x25mm 12V DC fan is an optimal choice for projects that require stable and effective reduction of component operating temperature.
