Motor speed PWM regulator controller 6-30V DC 8A CCM5D + LED display

Motor speed PWM regulator controller 6-30V DC 8A CCM5D + LED display

PWM motor controller with CCM5D driver is an advanced device for controlling DC motors in the voltage range from 6V to 30V. Thanks to PWM pulse technology, power losses are minimal, which translates into efficient operation and energy savings. It is ideal for controlling motor speed, charging current in battery chargers, temperature in heaters, or light intensity.

Key technical specifications

• Operating voltage range: 6-30V DC
• Rated current: 6A
• Maximum current: 8A
• Power: 120W
• Speed regulation: 0-100% (1% step), shown on a 3-digit LED display
• PWM frequency: 16 kHz
• Potentiometer: 100K Ohm on a lead approx. 18 cm long
• Momentary switch: on a lead approx. 17 cm long
• Enclosure dimensions: 78 x 43 x 27 mm
• Weight: 55 g

Benefits

• Precise control: allows accurate setting of motor speed from 0 to 100%.
• Low power losses: PWM technology ensures high efficiency and minimal power loss.
• Versatility: can be used to control charging current, temperature in heaters, and as a lighting dimmer.
• Ease of use: a clear LED display and wired potentiometer enable easy and intuitive adjustment.
• Reliability: high build quality ensures stable, long-term operation of the device under various conditions.

Example applications

• Controlling DC motor speed in electronics and robotics projects.
• Regulating charging current in battery chargers.
• Temperature control in heating systems and heaters.
• Smooth dimming of LED and traditional lighting.
• Use in home automation, workshops, and industrial machinery.

Package contents

• PWM motor controller driver 6-30V DC 8A CCM5D

Thanks to high build quality and advanced features, the CCM5D regulator provides reliable and precise control over DC-powered devices while offering simple operation and a wide range of applications.
