STM8 microcontroller development board module STM8S105K4T6 16MHz + goldpins

Developer board with microcontroller STM8S105K4T6 (8 bit) equipped with integrated peripherals for extended applications. The microcontroller operates at 16 MHz  using an internal oscillator or 8 MHz using an external quartz. There is 16 kB of Flash memory, 2 kB of SRAM and 1 kB of EEPROM, providing adequate space for application code and data.

The module also includes advanced communication interface options such as I2C, UART, SPI, LIN and IrDA for easy integration with other devices. In addition, the board is equipped with a 10-bit converter ADC and a variety of timers, expanding programming and control capabilities. The standard pin spacing allows seamless integration with contact boards, which is ideal for experimentation and prototyping.

Specification:

Clocking:

• Internal oscillator: 16 MHz
• External quartz: 8 MHz

Memory:

• SRAM: 16 kB
• Flash: 2 kB
• EEPROM: 1 kB

Supply voltage:

• USB: 5V
• ST-Link: 3.3V
• Regulator: 3.6V - 5.5V

Communication interfaces: I2C, UART, SPI, LIN, IrDA
A/C converter: 10-channel
Timers: 3 pieces
Programming: via ST-Link v2
Dimensions: 49.5 mm x 23 mm
Weight: 6.5 g
Additional functionalities:

• Indicator LED
• RESET" button
• Raster: 2.54 mm
• Built-in voltage regulator

Components on the board:

• LED
• Reset button
• Micro USB connector
• Goldpin connector for I/O ports (to be soldered individually)
• Goldpin terminals for the programmer (to be soldered by yourself)
• Set of 3 goldpin strips complete for self-soldering.
