Self Locking Ring 16mm Metal Switch 12-24V Green Backlit LED
0
Description
Self Locking Ring 16mm Metal Switch 12-24V Green Backlit LED
The switch has a mounting thread diameter of 16 mm, enabling easy installation in various devices. Green LED backlighting adds elegance and makes it easier to locate the button in the dark. The self-locking (Self Locking) switch with 12V-24V voltage and five pins (2.8 mm x 7 mm) ensures seamless integration with a wide range of electrical systems. The product is ideal for projects using microcontrollers - it works with Arduino, ESP8266, ESP32, and Raspberry Pi.
The kit includes a rubber gasket that additionally protects the switch from moisture and contaminants. The product features high electrical (50,000 cycles) and mechanical (500,000 cycles) life, making it an excellent choice for industrial and consumer applications.
This green-backlit metal 12V-24V LED switch combines functionality, durability, and modern design, providing reliability and ease of use in any conditions.
Key technical specifications
- Condition: New
- Switch type: Self Locking
- Voltage: 12V-24V
- Number of pins: 5 pins (2.8 mm x 7 mm)
- Electrical life: 50,000 cycles
- Mechanical life: 500,000 cycles
- Backlight colour: Green (button ring lit green)
- Material: High-quality brushed stainless steel, corrosion resistant
- Mounting thread diameter: 16 mm (Ø16 mm)
- Button diameter: 13 mm
- Dimensions: 18 mm x 35 mm
- Rubber gasket: Included
- Operating temperature: -20ºC to +55ºC
Example applications
- DIY microcontroller projects (Arduino, ESP32, ESP8266, Raspberry Pi)
- Control panels on industrial machines and workshop equipment
- Electrical installation modifications in vehicles (e.g. cars, motorcycles, boats)
- Smart home systems and building automation
- Custom PC cases and control panels
Benefits
- High durability: Brushed stainless steel construction ensures resistance to mechanical damage and corrosion.
- Reliable operation: Long mechanical life (500,000 cycles) ensures trouble-free performance for years.
- Easy use in the dark: Bright green ring LED backlighting makes the button easy to find.
- Environmental resistance: The included rubber gasket protects against moisture and contaminants.
- Versatility: A wide voltage range (12V-24V) suits many different electronic projects.
